Auto tracking video conferencing camera
Tracking is based on both face detection and motion detection technology, which ensures smooth and precise lock & track performance even in comprehensive scenarios.
Auto tracking video conferencing camera
Specifications:
| Image Sensor | 1/2.8″ Exmor CMOS, 2.14MP |
| Lens | f=3.9mm – 46.8mm; F1.6 – F2.8 |
| Zoom | Optical: 12X; Digital: 12X |
| Field of View | 72.5°- 6.3° |
| Focus | Auto, Manual, PTZ Trigger AF, One Push |
| Min. Illumination | 0.5 lux (Color), 0.1lux (B/W) |
| Shutter Speed | 1/1 ~ 1/10,000s |
| Gain | Auto / Manual |
| White Balance | Auto, Indoor, Outdoor, One Push, Manual, Automatic Tracking |
| AE Control | Auto, Manual, Shutter Priority, Iris Priority |
| S/N Ratio | ≥50dB |
| Full View Camera | |
| Image Sensor | 1/2.8″ Exmor CMOS |
| Effective Pixel | 2.14MP |
| White Balance | Auto |
| Exposure | Auto |
| Field of View | Horizontal: 86°; Vertical: 52° |
| Lens | 2.4mm |
| PTZ | |
| Pan/Tilt Angle | Pan: -170° ~ +170°/s; Tilt: -30° ~ +90°/s |
| Pan/Tilt Speed | Pan: 0.1° ~ 120°/s; Tilt: 0.1° ~ 90°/s |
| Preset Number | 256 |
| Control Interface | RS-232 / RS-485 / USB3.0 |
| Ethernet | RJ45, 100M |
| Control Protocol | PELCO-D / VISCA / UVC |
| Network | |
| Image Resolution | 1920 * 1080@60fps |
| Video Format | 1080P60 / 1080P50 / 1080P30 / 1080P25 1080I60 / 1080I50 / 720P60 / 720P50 |
| Video Compression | H.264 |
| Audio Compression | AAC |
| Network Protocol | ONVIF / RTSP / RTMP / TCP / UDP |
| Simultaneous Users | Up to 10 users |
| Dual Stream | Support |
| Video Interface | 3G-SDI / DVI-D / USB3.0 |
| General | |
| Power Supply | DC12V |
| Power Consumption | ＜20W |
| Working Temperature | 0°C ~ +40°C |
| Storage Temperature | -20°C ~ +60°C |
| Dimension | 243mm(L) x 145mm(W) x 163mm(H) |
| Color | Grey |
