Description
HD-820UNK Skype conference room camera – USB PTZ video conferencing camera
HD-820UNK USB PTZ Conference Camera widely used in Video Conferencing System
Features:
- USB 3.0 Interface
- Private Tooling design High Definition PTZ camera
- Fast and smooth video handling
- Power ON-OFF switch
- Work & Standby LED indicator
- Speed Match
- Auto/Manual focus/brightness/W
- RS-232C/VISCA Protocol
- Lens/Dome OSD
- Boundary scanning
- Standby & wakeup status
- Swap video format key
| Image Sensor | Image Sensor | 1/2.8″ Type Exmor CMOS |
| Effective Pix | 3.27 Megapixel | |
| Min. Illumination | 0.1Lux | |
| White balance | Auto/Manual | |
| Gain control | Auto/Manual | |
| Backlight compensation | On/Off | |
| Shutter speed | 1/1 – 1/10,000S | |
| S/N ratio | >50db | |
| Lens | Focus | f=4.7-90mmF1.6-3.5 |
| Iris | Auto/Manual | |
| Lens | 20 Optical x 12 digital zoom | |
| Horizontal view angle | 55.4 | |
| Video output | USB 3.0 | |
| Signal system | 1080P@30, 1080P@25, 1080i@60, 1080i@50, 720P@60, 720P@50, 720P@30, 720P@25, PAL,NTSC | |
| Control terminal | EIA/RS232C,EIA/RS485(Bidirectional) | |
| Control Protocol | VISCA,PELCO-D | |
| baud rate | 9600/38400bps | |
| patrol line | 4 cruise sequence | |
| preset position | 64 preset positions | |
| Speed Match | Pan/Tilt movement speed depends on camera module zoom in/out | |
| OSD Menu | Access to OSD Menu and adjust camera module parameters | |
| Image auto flip | Support Horizontal/Vertical image flip | |
| Pan movement speed | 1-200°/Second | |
| Tilt movement speed | 1-150°/Second | |
| Pan movement range | Pan: 0-355° | |
| Tilt movement range | Up: 45°, Down: 45° | |
| Pan scanning automatically | Support Pan scanning automatically | |
| Boundary scanning | 0-355°(programmable) | |
| Remote controller | IR Wireless Remote controller P/T/Z | |
| Power supply | DC12V,2A | |
| Work Temperature | 0-50°C | |
| Humidity | 0-95%RH | |
| size | 250mm x 140mm x 154mm | |
| Weight | 1380g | |
