Hundure HTA-830 Access control system

(1 customer review)

৳ 16,500

DIY Time & Attendance

Brand: Hundure


HTA-830 Hundure DIY Time & Attendance Access Control system in Bangladesh, Access control Bangladesh, Access control price in Bangladesh, Hundure rac-960pe, Access control importer Bangladesh,  Hundure price list in Bangladesh, HTA-830 Hundure distributor in Bangladesh.

Hundure HTA830 Access control system

Features :

  • 16 Duty Timetable.
  • 32 sets siren output.
  • Memory full warning.
  • Suitable for chains and enterprises.
  • Built-in TCP/IP communication interface to PC.
  • Watchdog function ensures device free from halting.
  • At least 60 days data storage in case of power outage.
  • Cope with seasonal time change – daylight saving control.
  • Simple, reliable & easily installed, first time set up in 3 minutes.
  • Follows your usual practice – auto or manual clock in / clock out.
  • Invalid & re-swiped cards off-the-record saves memory capacity.
  • Auto scheduling for data collection, time synchronization, valid card download.
  • RTC (Real Time Clock) ensures accurate time regardless of power outage.
  • Dynamic control of memory up to 8000 cardholders (max), 8200 transaction data.
  • Visual LED for display of time, card number, communication mode, swiped card indication.
  • PoE (Power Over Ethernet) for HTA-840, eliminates serial cable material & installation, power adapter – significant cost saving.



Model No.HTA-830HTA-840
Cardholders/Events8,000 / 8,200
KeypadDuty switch by A, B, C, D
Output Ports1 Relay (Siren / Door Lock)
LED IndicatorVisual LED for display of time, Swiped card indication (last 4 digits), Comm. x 1
Real Time ClockYes
Beep ToneBuzzer
IP SettingSoftware
Read Format & RangeABA-Track2 / Wiegand x 1
● EMRF 125 KHz, 8~10cm (max.)
● Mifare®RF 13.56 MHz, 5cm (max.)
Power InputDC 12V / 1APower PoE HUB
Power Consumption500A (max.)
Comm. InterfaceTCP/IPTCP/IP (PoE)
Comm. Baud Rate10/100 Mbps
Operating Temp.-10° C ~ 55° C / 14° F ~ 131° F
Relative Humidity20% ~ 80%(Non-condensing)
Dimension160mm(L) x 100mm (W) x 40mm (H) (excluding base)
Weight (Device)400g
